digital pressure gauges

Presenting the DM 01 Digital Pressure Gauge: a precision instrument meticulously crafted to meet the most stringent requirements. This state-of-the-art gauge is purpose-built for process monitoring and calibration, setting a new standard in accuracy and reliability.

The DM 01 stands out with its dual-component configuration, featuring a digital display and a seamlessly integrated pressure transmitter. On-site adaptability is at your fingertips, as the pressure transmitter can be effortlessly selected to accommodate various measuring ranges and connected to the display without the need for tools or parameter adjustments.

Experience exceptional measurement capabilities, a user-friendly interface, and an innovative modular sensor concept that redefine expectations. Powered by batteries, this digital pressure gauge is perfect for applications such as pressure course control and pressure transmitter calibration.

Moreover, the integrated data logger captures linear and cyclic pressure and temperature values, providing a comprehensive dataset for analysis through the included DAQ software. Elevate your pressure measurement experience—explore the DM 01 and its innovative features today.

Immerse yourself in unprecedented precision with the DL01 Digital Pressure Gauge. Engineered to excel in demanding tasks like leak testing and pipeline monitoring, this state-of-the-art device seamlessly combines a digital display and pressure transmitter, eliminating the need for tools during assembly. Its exceptional versatility allows it to adapt swiftly to various mounting setups within seconds, streamlining your toolkit for maximum efficiency.

The DL01 stands out with unmatched measurement accuracy, intuitive operation, and an integrated data logger that defines its excellence. The user-friendly graphic display ensures clear procedure visualization, enhancing overall usability. Seamlessly collect and manage crucial data, complete with TAGs and serial numbers, using the built-in USB interface and PC software.

Revolutionize your pressure measurement experience with the DL01 Digital Pressure Gauge, setting a new standard for precision and ease of use in your applications.

• Range: from 100 mbar up to 600 bar
• Main Features: 2-line LC display 4.5-digit 7-segment display 6-digit 14-segment additional display, offset and end point calibration, min / max function with reset function

• Range: from 6 bar up to 600 bar
• Main Features: accuracy: 0,5 % FSO BFSL (class 0,5), adjustable housing, LC display, 4,5-digit 7-segment display, standard battery CR 2450 operating period > 1.500h

• Range: from 400 mbar up to 600 bar
• Main Features: 2-line LC display, 4.5-digit 7-segment display, 6-digit 14-segment additional display, different mechanical connections: inch, NPT threads, offset and end point calibration

• Range: from 60 bar up to 400 bar
• Main Features: 2-line LC display, 4.5-digit 7-segment display, 6-digit 14-segment additional display, offset and end point calibration, min / max function with reset function, rotatable housing

• Pressure Ranges: Nominal pressure from 0 … 1.6 bar up to 0 … 250 bar
• Accuracy: 4.5-digit 7-segment display for precise readings
• Electrical Connections: Powered by a standard battery (CR 2450)
• Process Connections: Rotatable housing and display for flexible installation
• Media Compatibility: Suitable for various media types
• Special Features: Long battery life (>1,500 hours), min/max function with reset, auto-zero function, configurable automatic shut-off, unit selection (bar, mbar, psi, MPa, mH2O)

• Range: from 6 bar up to 600 bar
• Main Features: accuracy: 0,5 % FSO BFSL (class 0,5), adjustable housing, LC display, 4,5-digit 7-segment display, standard battery CR 2450 operating period > 1.500h
